Veil Nebula

mouse over for annotated version - click for full resolution

Mosaic of two frames planned with MosaicMaker

The Veil Nebula is a cloud of heated and ionized gas and dust in the constellation Cygnus. It constitutes the visible portions of the Cygnus Loop, a supernova remnant, many portions of which have acquired their own individual names and catalogue identifiers. The source supernova was a star 20 times more massive than the Sun which exploded between 10,000 and 20,000 years ago. At the time of explosion, the supernova would have appeared brighter than Venus in the sky, and visible in daytime. The remnants have since expanded to cover an area of the sky roughly 3 degrees in diameter (about 6 times the diameter, and 36 times the area, of the full Moon). While previous distance estimates have ranged from 1200 to 5800 light-years, a recent determination of 2400 light-years is based on direct astrometric measurements. [Wiki]

Optic SW Quattro 8S 200mm f/4 with Baader MPCC Mark III corrector
Camera Atik 383L+
Filters Baader Ha, OIII, 36mm
Mount NEQ6 with EQASCOM
SW 70/500 with AlCCD5
Frame center
RA 20:55:58 DEC 31:24:28 J2000
July 2022
Astrobioparco di Felizzano, AL, Italy
Exposures Ha - 40x900 bin 1x1 @-10C
OIII - 60x900s bin 2x2

Integration time - 25h
